Series 455 - 7 RKS

455 80 70 SW 7RKS

Name: Swivel castor 80/35 mm, black
SKU: 455 80 70 SW 7RKS

Intro

The Series 455 7 RKS combines a galvanized sheet steel housing in black with a double-row ball and cage assembly and the non-marking wheel 7 RKS with black elastic solid rubber tyres. With roller bearing, high load capacity and quiet running properties. Temperature range -30 °C to +80 °C. Rolling resistance group 5. RoHS-compliant and 100 % PAH-free - for durable, clean transport solutions.

Technical details

Download data sheet

Swivel castor 80/35 mm, black

Wheel diameter

80 mm
Load capacity

100 kg
Overall height

100 mm
Plate size

105x85 mm
Wheel width

35 mm
Screw hole diameter

9 mm
Tread material

Elasticated bandage
Housing material

Sheet steel
Wheel type

Swivel castor
Warehouse

Roller bearing
Locking device

-
Minimal screw hole removal

80x60 mm
Running surface Shore

70

All product variants

Product name	Wheel diameter	Load capacity	Overall height	Plate size	Actions
455 80 70 SW 7RKS	80 mm	100 kg	100 mm	105x85 mm
455 100 70 SW 7RKS	100 mm	150 kg	125 mm	105x85 mm	455 100 70 SW 7RKS from series Series 455 - 7 RKS
455 125 70 SW 7RKS	125 mm	200 kg	155 mm	105x85 mm	455 125 70 SW 7RKS from series Series 455 - 7 RKS
455 T 80 70 SW 7RKS	80 mm	100 kg	100 mm	105x85 mm	455 T 80 70 SW 7RKS from series Series 455 - 7 RKS
455 T 100 70 SW 7RKS	100 mm	150 kg	125 mm	105x85 mm	455 T 100 70 SW 7RKS from series Series 455 - 7 RKS
455 T 125 70 SW 7RKS	125 mm	200 kg	155 mm	105x85 mm	455 T 125 70 SW 7RKS from series Series 455 - 7 RKS
