Wheels 7 RKB

7 RKB 100 12

Name: Elasticated solid rubber wheel 100/36 mm
SKU: 7 RKB 100 12

Intro

Wheel 7 RKB is equipped with an elastic solid rubber bandage in blue and has a durable roller bearing. It offers a high level of ride comfort, is floor-friendly, non-marking and ideally suited for sensitive surfaces. With a high load capacity and a temperature range of -30 °C to +80 °C, it can be used for a wide range of applications. Rolling resistance group 5 - quiet, stable and reliable in continuous use.

Technical details

Download data sheet

Elasticated solid rubber wheel 100/36 mm

Wheel diameter

100 mm
Load capacity

150 kg
Wheel width

36 mm
Tread material

Elastic solid rubber
Warehouse

Roller bearing
Hub length

40 mm
Locking device

-
Axle bore

12 mm
Running surface Shore

70

All product variants

Product name	Wheel diameter	Load capacity	Actions
7 RKB 100 12	100 mm	150 kg
7 RKB 80 12	80 mm	100 kg	7 RKB 80 12 from series Wheels 7 RKB
7 RKB 125 15 49 NL	125 mm	200 kg	7 RKB 125 15 49 NL from series Wheels 7 RKB
7 RKB 160 20	160 mm	350 kg	7 RKB 160 20 from series Wheels 7 RKB
7 RKB 200 20	200 mm	400 kg	7 RKB 200 20 from series Wheels 7 RKB
