Small Line

SKD 176 S X

Name: short chair column, swivelling only, black
SKU: SKD 176 S X

Intro

The SKD column is the compact version of the SD - swivelling but not height-adjustable. With its low overall height, it is perfect for lounge chairs or chairs in combination with a high base. Stable, space-saving and ideal for stylish seating solutions with a fixed height and swivelling comfort.

Technical details

Download data sheet

short chair column, swivelling only, black

Colour: black
Total height lowest position mm: 176 mm
Functions
Drehbar
Weight limit
140 kg
Class
4
Diameter gas unit
28 mm
Cone length gas unit
33 mm
Cone length
48 mm
Total height Highest position mm
176 mm
Standpipe length
122 mm
Standpipe diameter
50 mm
Build-up height from foot Min.
129 mm
Installation height from foot Max.
129 mm
Material: Sheet steel
Pressure
320 N
Bolting pattern
-
Rotatable
yes

All product variants

Product name	Colour	Total height lowest position mm	Functions	Actions
SKD 176 S X	black	176 mm	Drehbar
SKD 148 C X	chrome	148 mm	Drehbar	SKD 148 C X from series Small Line
SKD 148 S X	black	148 mm	Drehbar	SKD 148 S X from series Small Line
SKD 161 C X	chrome	161 mm	Drehbar	SKD 161 C X from series Small Line
SKD 176 C X	chrome	176 mm	Drehbar	SKD 176 C X from series Small Line
