Spindle

SD 260 310 140 K 70 S/C X

Name: Chair spindle column, black
SKU: SD 260 310 140 K 70 S/C X

Intro

Precise, low-maintenance and robust: the SD column offers infinitely variable height adjustment via a rotating spindle with concealed steel threaded rod. The integrated locking mechanism prevents unintentional adjustment and ensures a permanently secure fit. Ideal for work, laboratory or contract chairs where precise adjustment and long-lasting function are required.

Technical details

Download data sheet

Chair spindle column, black

Colour

black
Total height lowest position mm

310 mm
Stroke

140 mm
Functions

Drehbar,Höhenverstellbar
Weight limit

140 kg
Class

4
Diameter gas unit

28 mm
Cone length gas unit

33 mm
Cone length

70 mm
Total height Highest position mm

450 mm
Standpipe length

260 mm
Standpipe diameter

50 mm
Build-up height from foot Min.

190 mm
Installation height from foot Max.

380 mm
Bolting pattern

-
Rotatable

yes

All product variants

Product name	Colour	Total height lowest position mm	Stroke	Functions	Actions
SD 260 310 140 K 70 S/C X	black	310 mm	140 mm	Drehbar,Höhenverstellbar
SD 205 260 80 K 70 S X	black	260 mm	80 mm	Drehbar, Höhenverstellbar	SD 205 260 80 K 70 S X from series Spindle
SD 300 344 190 K 70 S X	black	344 mm	190 mm	Drehbar, Höhenverstellbar	SD 300 344 190 K 70 S X from series Spindle
